Overview
A quad-sensor pod with tele/wide EO, thermal IR and laser ranging, plus onboard small-target detection and EO/IR fusion for detection, recognition, tracking and high-accuracy localization of distant small targets.
Highlights
- Multispectral fusion sensing
- High-precision laser ranging
- All-around environmental awareness
- Compatible with multiple UAV platforms
- Built for inspection and reconnaissance
Key Features
- Quad-sensor fusion: telephoto, wide-angle, IR and laser ranging work together for multi-dimensional target information.
- Onboard AI recognition: lightweight detection and image processing on the pod reduce link latency and bandwidth use.
- Small-target detection: real-time detection and tracking of distant small objects for better recognition in cluttered scenes.
- Multispectral fusion: EO/IR fusion lowers daytime false alarms and strengthens nighttime thermal-target recognition.
- High-precision positioning: laser ranging provides target distance for latitude/longitude calculation and accurate geolocation.
- Multi-target intelligent recognition and tracking: supports multi-scenario recognition, tracking and positioning for inspection, reconnaissance, emergency response and more.
Specifications
| IR | 640×512, 19 mm, NETD≤65 mK |
|---|---|
| Tele EO | ≥3864×2192, 16 mm |
| Wide EO | ≥3864×2192, 3 mm |
| LRF | 5–1000 m, ±1 m, 905 nm |
| Servo | Az ±30°, El -120°~+30°, ≤0.01° |
| Weight | ≤230 g |
